    Automatic Adjustment YS-3F TRIAC Relays Overheat Protection Function

    Ask Lasest Price
    Brand Name : YSUN
    Model Number : YS-3F
    Certification : cULus:E509779/TUV:B1067040001/CQC:CQC21107292207
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram, L/C, D/A, D/P
    Supply Ability : 500k per month
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Automatic Adjustment YS-3F TRIAC Relays Overheat Protection Function

    Automatic Adjustment YS-3F TRIAC Relays Overheat Protection Function


    TRIAC Relays Description:

    The relay is an electric control device, which is an electrical appliance that causes the controlled quantity to undergo a predetermined step change in the electrical output circuit when the change of the input quantity meets the specified requirements. It has an interactive relationship between the control system and the controlled system. Usually used in automatic control circuits, it is actually an "automatic switch" that uses a small current to control the operation of a large current. Therefore, it plays the role of automatic adjustment, safety protection, and conversion circuit in the circuit.


    TRIAC Relays Features:

    1. Load voltage can reach 280VAC

    2. Zero-cross and non-zero-cross as trigger mode

    3. Dielectric strength 5000VAC


    TRIAC Relays Technical Parameters:

    Electric parameters(Environment temperature:25℃)

    Item

    Symbol

    Test condition

    Min

    Typical

    Max

    Unit

    Input

    LED Forward voltage

    VF

    IF=10mA


    1.16

    1.3

    V

    LED Reverse current

    IR

    VR=6V IF=0mA


    0.1

    10

    μA

    Output

    Peak off-state current

    IDRM

    VDRM=600V



    100

    μA

    Peak on-state voltage drop

    VTM




    2.5

    V

    Holding current

    IH

    IFTM=Max



    25

    mA

    Rise rate off-state critical voltage

    dv/dt

    VDRM=600Vx1/√2


    200


    V/μs

    Transmission

    LED trigger current

    IFT

    VD=6V RL=100Ω


    10


    mA

    Turn-on time

    Ton


    1


    10

    ms

    Turn-off time

    Toff




    10

    ms

    Insulation resistance

    Riso

    500VDC(input-output)


    50


    Weight





    0.58


    g


    TRIAC Relays Applications:

    1. Traffic light system

    2. Security systems

    3. Computer peripheral interface

    4. Remote system

    Automatic Adjustment YS-3F TRIAC Relays Overheat Protection Function
