    Versatile Compact PCB Solid State Relay 24VDC Input 200mW Rated Power

    Ask Lasest Price
    Brand Name : WRG
    Model Number : RC-112DM
    Certification : TUV/CQC/UL/VDE
    Price : negotiable
    Payment Terms : T/T, Western Union, L/C, MoneyGram
    Supply Ability : 500k per month
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    Versatile Compact PCB Solid State Relay 24VDC Input 200mW Rated Power

    Versatile Compact PCB Solid State Relay 24VDC Input 200mW Rated Power


    WRG Relay Versatile Compact PCB Relay With 24V DC Input And 200mW Rated Power


    WRG Relay Description:

    Our Compact PCB Relay is a versatile solution for your electrical needs. It utilizes a 24V DC input and features a power rating of 200mW. This low-power consumption characteristic makes it an energy-efficient choice for various applications. Despite its compact size, this relay ensures robust performance, making it ideal for incorporation into various electrical and electronic devices. It guarantees seamless switching operations, hence significantly enhancing the efficiency of your systems. With its compact form factor, it offers the benefit of easy installation, saving valuable space on your PCB.


    WRG Relay Features:

    1. rated current 3A,4pin

    2. coil power 200mW

    3. lightweight, high sensitivity
    4. ultra-slim,7mm width
    5. Meet with IEC60079-15 anti-explosion standard


    WRG Relay Specification:

    General data
    Rated withstand impulse voltagecoil contact4kV AC/1min
    between contact750V AC/1min
    Surge voltage10kV AC(1.2/50μs)
    Insulation resistance1000MΩ(500VDC)
    VibrationFault 10-55Hz(amplitude 1.5mm)
    Endurance 10-55Hz(amplitude 1.5mm)
    ShockFault 98m/S2 Endurance 980m/S2
    Dimension LxWxH(mm)20.4x7.0x15.1
    Enclosure typeFlux-resistance, sealed
    CertificationscULus:E345228/TUV:R50220640/CQC:CQC12002067898/VDE:40034781
