Brand Name : | NBC |
Model Number : | BM940-C-S |
Certification : | RoHS |
Price : | negotiable |
Payment Terms : | T/T, Western Union, MoneyGram |
Supply Ability : | 500k per month |
Delivery Time : | 4weeks |
AgNi 12V 50A Relay Automatic Adjustment Sensitivity Safety Protection
12V 50A Relay Introduce:
The relay is an electrical control device, which can give a specified input quantity and keep it for a long enough time so that the controlled quantity will undergo a predetermined step change in the electrical output circuit. When the input volume drops to a certain level and maintains for a long enough time, it returns to the initial state.
12V 50A Relay Features:
1. 5A contact switching capability
2. Standard printed board pinout
3. The dielectric withstand voltage between the contact and the
coil is 1KV
4. It has a set of normally open, normally closed, and conversion
contacts
5. UL insulation class: Class F insulation class
6. Dimensions: 15.5 x 11 x 11.5mm
12V 50A Relay Technical Rating:
Contact Rating | |||
Contact Form | 1A:NO; 1B:NC; 1C:SPDT | ||
Contact Material | Ag; AgNi | ||
Contact Load Capacity | 1A, 2A,3A, 5A/125VAC,30VDC | ||
Switching Power Max. | 150W 625VA | ||
Switching Voltage Max. | 60VDC 250VAC | ||
Switching Current Max. | 5A | ||
Contact Resistance | ≤100mΩ | IEC 255-7 3.12 | |
Life expectancy | Electrical | 10^5 | IEC 255-7 3.30 |
Mechanical | 10^7 | IEC 255-7 3.31 |
![]() |
