    Sealed 12 Volt 30A Power Relay SPDT 2.5KV NB901E-12S-S-C For EV Charger Station

    Sealed 12 Volt 30A Power Relay SPDT 2.5KV NB901E-12S-S-C For EV Charger Station


    30A Power Relay Description:

    New energy products, like electric vehicles, must be a trend in the next few days. So more and more fast-charging stations are made and satisfy the need for electric cars power-charging.NB90 series relay is specially applied to the charging point. It is a high switching capacity for contacts, is a dust-proof or sealed type option, and is environmentally friendly.


    30A Power Relay Features:

    1. 4000VAC or 2500VAC is available for dielectric to withstand voltage between contact and coil.

    2. Class F for coil insulation grade.

    3. Sealed-type or open-type for options.

    4. SPDT & SPST.

    5. Rated current max 40A.

    6. 900mW.

    7. TUV/CQC/UL certification.


    30A Power Relay Note:

    1. Using under a clean environment(excluding H2S, SO2, NO2, dust contaminants), dust-proof type is recommended; Using under a polluted environment(containing H2S, SO2, NO2, dust contaminants), sealed type is recommended, and please contact us during practical applying;

    2. If the dielectric strength between the coil & contacts has to be over 2500VAC, please inform us before ordering, so as to provide the proper types.

    30A Power Relay Specification:

    Insulation Resistance:1000MΩ
    Dielectric Strength(Between coil&contact):2500VAC
    Operate Time (Max.):15ms
    Release Time (Max.):10ms
    Ambient Temperature:-40℃ ~ 85℃/105℃
    Terminal Type:THT & QT
