24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V

Shenzhen Ketai Electronic Technology Co., Ltd.
Contact Now
    Buy cheap 24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V from wholesalers

    Buy cheap 24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V from wholesalers
    • Buy cheap 24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V from wholesalers

    24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V

    Ask Lasest Price
    Brand Name : NBC
    Model Number : MQ8-A-S-DC24V
    Certification : CQC:CQC22002329832/TUV:R50518131
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500k per month
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V

    24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V


    Universal Automotive Relay Description:

    MQ8 series relays are widely used for automotive products, small in size, safe and reliable, long-lasting, perfectly compatible with G8QNxxx of Omron, HFKWxxx of Hongfa,895xxx of Songchuan, etc.


    Universal Automotive Relay Feature:

    1. Durable, safe, and reliable

    2. Low coil power 0.36W / 0.6W

    3. Small size, lightweight

    4. Widely used for fan control, car flame glowplug, car horn, etc.


    Universal Automotive Relay Name rule :

    MQ8 - C -S -DC12V

    1. Model No.

    2. Contact Form: A: Normally open B: Normally Close C: Normally open & close

    3. Construction: S: Sealed type E: Flux tight type

    4. Normal Coil Voltage: 5,6,9,12,18,24(DC)

    Universal Automotive Relay Coil Rating:

    No.Coil Voltage(VDC)Coil ResistanceΩ±10%Pick up (VDC) Max. (75% of Rated Voltage)Drop out (VDC) Min. (10% of Rated Voltage)Power (W)Operate Time (ms)Release Time (ms)
    RatedMax.
    005-25055.5423.50.50.6≤10≤5
    006-25066.6604.20.6
    009-25099.91356.30.9
    012-2501213.22408.41.2
    024-2502426.496016.82.4
    005-54055.5313.50.50.8≤10≤5
    006-54066.6454.20.6
    009-54099.91016.30.9
    012-5401213.21808.41.2
    024-5402426.472016.82.4
